Rexroth | R902444032 | AA10VO71DFR1/31R-PSC12K01E
AXIAL PISTON PUMP A10VO71
Reference number:
TPH002319
Weight:
35 kg
| Condition: | New |
|---|
Description
AXIAL PISTON PUMP
For machines with medium pressure requirements
• Nominal pressure 250 bar (3600 psi)
• Maximum pressure 315 bar (4550 psi)
• Open circuit
Features:
• Variable displacement pump with axial piston drive unit in swash plate design for hydrostatic drives in open circuit
• The volume flow is proportional to the drive speed and the displacement volume.
• The flow rate can be infinitely varied by adjusting the swash plate.
• Stable bearing for long service life
• High permissible drive speed
• Favorable power-to-weight ratio - small dimensions
• Low noise level
• Good suction behavior
• Electro-hydraulic pressure control
• Power control
• Electro-proportional swivel angle control
• Short control times
| Control: | DFR1 |
|---|---|
| Direction of rotation: | R |
| Gross weight: | 38.5 kg |
| Net weight: | 38.5 kg |
| Nnom Nominal Rotational Speed: | 2200 rpm |
| Operation: | O |
| Pnom Nominal Pressure: | 280 bar |
| Series: | 3 |
| Size: | 71 |
| Type: | A10V |
