Rexroth | 0510110326 | AZPB-32-2.0LNM02MB
EXTERNAL GEAR PUMP
Reference number:
TPH056408
Weight:
1 kg
| Condition: | New |
|---|---|
| Machine: | R9350, R9800, R9250, R9400, R9400E, R994, R9350E |
| OEM: | Liebherr |
Description
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
| Direction of rotation: | Counter-clockwise rotation |
|---|---|
| Drive shaft: | Tang drive |
| Front cover: | 2-bolt dia. 32 mm, with O-ring |
| Function: | Pump |
| Gross weight: | 1 kg |
| Housing material: | Aluminum |
| Max.intermittent pressure: | 250 bar |
| Maximum rotational speed: | 5000 rpm |
| Model: | High perf(B)(1.0..7.1 cc/rev) |
| Net weight: | 1 kg |
| Noise level: | Standard noise level |
| Nominal size: | 2 cm³/rev |
| Port connection: | Metric thread, ISO 9974-1 |
| Product: | External gear unit |
| Rear cover: | Standard (cast iron) |
| Sealing material: | NBR |
| Series: | Bearing dia. 12 mm or 12.7 mm |
| Version: | Zn plated or Al, aligned cover |
| Weight: | 1 kg |
